Name: DJI Mavic 3 Enterprise Thermal
SKU: DJIMAVIC3ENTT
Availability: OutOfStock

Description

The DJI Mavic 3 Enterprise Thermal Universal Edition Drone redefines industry standards for small commercial drones. With a mechanical shutter, a 56x zoom camera, and an RTK module for centimeter-level precision, the Mavic 3E brings mapping and mission efficiency to new heights. A thermal version is available for firefighting, search and rescue, inspection, and night operations.

Mavic 3E’s Wide camera has large 3.3m pixels that, together with intelligent low-light mode, offer significantly improved performance in dim conditions. Both Mavic 3E and Mavic 3T are equipped with a 12MP Zoom Camera, supporting up to 56x Max Hybrid Zoom to see essential details from afar.

Mavic 3T’s thermal camera has 640 x 512 resolution and supports point and area temperature measurement, high temperature alerts, color palettes, and isotherms to help you find your targets and make quick decisions. Mavic 3T’s thermal and zoom cameras support 28x continuous side-by-side zoom for easy comparisons.

Features

Survey with Speed
Improved Low-Light Performance
Focus and Find
See the Unseen
Simultaneous Split-Screen Zoom
4/3 CMOS Wide Camera
640 x 512 px Thermal Camera
45-min Max Flight Time
DJI O3 Enterprise Transmission
Centimeter-level Positioning with RTK
High-Volume Loudspeaker
56x Hybrid Zoom

Specifications

Aircraft

Weight (With Propellers, Without Accessories)

920 g

Max Takeoff Weight

1,050 g

Dimensions

Folded (without propellers): 221×96.3×90.3 mm (LxWxH), Unfolded (without propellers): 347.5x283x107.7 mm (LxWxH)

Diagonal Distance

380.1 mm

Max Ascent Speed

6 m/s (Normal Mode), 8 m/s (Sport Mode)

Max Descent Speed

6 m/s (Normal Mode), 6 m/s (Sport Mode)

Max Flight Speed (At Sea Level, No Wind)

15 m/s (Normal Mode), Forward: 21 m/s, Side: 20 m/s, Backward: 19 m/s (Sport Mode)

Max Wind Speed Resistance

12 m/s 3

Max Take-off Altitude Above Sea Level

6000 m (without payload)

Max Flight Time (No Wind)

45 mins 4

Max Hover Time (No Wind)

38 mins

Max Flight Distance

32 km

Max Tilt Angle

30-Degrees (Normal Mode), 35-Degrees (Sport Mode)

Max Angular Velocity

200-degrees/s

GNSS

GPS+Galileo+BeiDou+GLONASS (GLONASS is supported only when the RTK module is enabled)

Hovering Accuracy

Vertical: 0.1 m (with Vision System) 0.5 m (with GNSS) 0.1 m (with RTK), Horizontal: 0.3 m (with Vision System) 0.5 m (with High-Precision Positioning System) 0.1 m (with RTK)

Operating Temperature Range

-10 to 40 C (14 to 104 F)

Internal Storage

N/A

Motor Model

2008

Propeller Model

9453F Propellers for Enterprise

Beacon

Built into the aircraft

Wide Camera

Sensor

DJI Mavic 3T: 1/2-inch CMOS, Effective pixels: 48 MP

Lens

DJI Mavic 3T: FOV: 84-Degrees, Format Equivalent: 24 mm, Aperture: f/2.8, Focus: 1 m to Infinity

ISO Range

DJI Mavic 3T: 100-25600

Shutter Speed

DJI Mavic 3T: Electronic Shutter: 8-1/8000 s

Max Image Size

DJI Mavic 3T: 8000×6000

Still Photography Modes

DJI Mavic 3T: Single: 12 MP/48 MP, Timed: 12 MP/48 MP, JPEG: 2/3/5/7/10/15/20/30/60 s, Panorama: 12 MP (raw image) 100 MP (stitched image), Smart Low-light Shooting: 12 MP, Shooting 48MP photo does not support 2s interval

Video Resolution

H.264, 4K: 3840×2160@30fps, FHD: 1920×1080@30fps

Bitrate

DJI Mavic 3T: 4K: 85 Mbps, FHD: 30 Mbps

Supported File Formats

exFAT

Photo Format

DJI Mavic 3E: JPEG/DNG (RAW), DJI Mavic 3T: JPEG

Video Format

MP4 (MPEG-4 AVC/H.264)

Tele Camera

Sensor

1/2-inch CMOS, Effective pixels: 12 MP

Lens

FOV: 15-Degrees, Format Equivalent: 162 mm, Aperture: f/4.4, Focus: 3 m to Infinity

ISO Range

DJI Mavic 3T: 100-25600

Shutter Speed

Electronic Shutter: 8-1/8000 s

Max Image Size

4000×3000

Photo Format

JPEG

Video Format

MP4 (MPEG-4 AVC/H.264)

Still Photography Modes

DJI Mavic 3T: Single: 12 MP, Timed: 12 MP, JPEG: 2/3/5/7/10/15/20/30/60 s, Smart Low-light Shooting: 12 MP

Video Resolution

H.264, 4K: 3840×2160@30fps, FHD: 1920×1080@30fps

Bitrate

DJI Mavic 3T:, 4K: 85 Mbps, FHD: 30 Mbps, Digital Zoom, 8x (56x hybrid zoom)

Thermal Camera

Thermal Imager

Uncooled VOx Microbolometer

Pixel Pitch

12 m

Frame Rate

30 Hz

Lens

DFOV: 61-Degrees, Format Equivalent: 40 mm, Aperture: f/1.0, Focus: 5 m to Infinity

Sensitivity

<50 mk@F1.1

Temperature Measurement Method

Spot Meter, Area Measurement

Temperature Measurement Range

-20 to 150 C (-4 to 302 F, High Gain Mode), 0 to 500 C (32 to 932 F, Low Gain Mode)

Palette

White Hot/Black Hot/Tint/Iron Red/Hot Iron/Arctic/Medical/Fulgurite/Rainbow 1/Rainbow 2

Photo Format

JPEG (8-bit), R-JPEG (16-bit)

Video Resolution

640×512@30fps

Bitrate

6 Mbps

Video Format

MP4 (MPEG-4 AVC/H.264)

Still Photography Modes

DJI Mavic 3T: Single: 640×512, Timed: 640×512, JPEG: 2/3/5/7/10/15/20/30/60 s

Digital Zoom

28x

Infrared Wavelength

8-14 m

Infrared Temperature Measurement Accuracy

+-2 C or +-2% (using the larger value)

Gimbal

Stabilization

3-axis (tilt, roll, pan)

Mechanical Range

DJI Mavic 3T: Tilt: -135 to 45-Degrees, Roll: -45 to 45-Degrees, Pan: -27 to 27-Degrees

Controllable Range

Tilt: -90 to 35-Degrees, Pan: Not controllable

Max Control Speed (Tilt)

100-Degrees/s

Angular Vibration Range

+-0.007-Degrees

Sensing

Type

Omnidirectional binocular vision system, supplemented with an infrared sensor at the bottom of the aircraft.

Forward

Measurement Range: 0.5-20 m, Detection Range: 0.5-200 m, Effective Sensing Speed: Flight Speed <15 m/s, FOV: Horizontal 90-Degrees, Vertical 103-Degrees

Backward

Measurement Range: 0.5-16 m, Effective Sensing Speed: Flight Speed <12 m/s, FOV: Horizontal 90-Degrees, Vertical 103-Degrees

Lateral

Measurement Range: 0.5-25 m, Effective Sensing Speed: Flight Speed <15 m/s, FOV: Horizontal 90-Degrees, Vertical 85-Degrees

Upward

Measurement Range: 0.2-10 m, Effective Sensing Speed: Flight Speed <6 m/s, FOV: Front and Back 100-Degrees, Left and Right 90-Degrees

Downward

Measurement Range: 0.3-18 m, Effective Sensing Speed: Flight Speed <6 m/s, FOV: Front and Back 130-Degrees, Left and Right 160-Degrees

Operating Environment

Forward, Backward, Lateral, and Upward: Surface with a clear pattern and adequate lighting (lux >15), Downward: Diffuse reflective surface with diffuse reflectivity>20% (e.g. walls, trees, people) and adequate lighting (lux >15)

Video Transmission

Video Transmission System

DJI O3 Enterprise Transmission

Live View Quality

Remote Controller: 1080p/30fps

Operating Frequency

2.400-2.4835 GHz, 5.725-5.850 GHz

Max Transmission Distance (Unobstructed, Free of Interference)

DJI Mavic 3T: FCC: 15 km, CE: 8 km, SRRC: 8 km, MIC: 8 km

Max Transmission Distance (Obstructed)

Strong Interference (dense buildings, residential areas, etc.): 1.5-3 km (FCC/CE/SRRC/MIC), Medium Interference (suburban areas, city parks, etc.): 3-9 km (FCC), 3-6 km (CE/SRRC/MIC), Low Interference (open spaces, remote areas, etc.): 9-15 km (FCC), 6-8 km (CE/SRRC/MIC)

Max Download Speed

15 MB/s (with DJI RC Pro Enterprise)

Latency (Depending On Environmental Conditions And Mobile Device)

Approx. 200 ms

Antenna

4 Antennas, 2T4R

Transmission Power (EIRP)

2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC), 5.8 GHz: <33 dBm (FCC), 30 dBm (SRRC), <14 dBm (CE)
